Understanding Traefik, Keycloak, and ForwardAuth

How to add centralized authentication to Kubernetes services using Traefik ForwardAuth, Keycloak, and OAuth2-Proxy.

• Updated March 15, 2026 • 15 min read

We deployed Grafana, an admin panel, and an API server to our Kubernetes cluster — and then realized anyone who knew the URL could walk right in. No authentication, no access control, nothing. The obvious fix was adding login logic to each service, but that meant duplicating auth code everywhere and maintaining it in three different places.

What we needed was a single, centralized auth gate that protects multiple services without any of them needing to implement authentication themselves. This post explains how Traefik’s ForwardAuth middleware, Keycloak as an identity provider, and OAuth2-Proxy as the glue between them solve this problem — using a building analogy that makes the architecture intuitive.

Difficulties Encountered

  • Cross-namespace middleware references are undocumented: Traefik’s ForwardAuth middleware must be in the same namespace as the IngressRoute, or use a middleware@namespace syntax that is barely mentioned in the docs. Initial attempts with cross-namespace references silently failed with no error — requests just bypassed auth entirely.
  • OAuth2-Proxy configuration is sprawling: OAuth2-Proxy has 100+ configuration flags. Finding the correct combination for Keycloak OIDC (issuer URL format, scope requirements, cookie domain settings) required extensive trial-and-error because most examples online use Google or GitHub as the provider, not Keycloak.
  • Redirect loops on misconfigured cookie domains: If the cookie domain does not match the service domain exactly, the browser never sends the auth cookie back, causing an infinite redirect loop between OAuth2-Proxy and Keycloak that produces no useful error message.
  • OIDC discovery endpoint path varies by Keycloak version: Keycloak changed its default URL structure between versions (with and without /auth/ prefix), causing “issuer mismatch” errors that looked like a configuration problem but were actually a version compatibility issue.
  • ForwardAuth subrequests are invisible: When ForwardAuth denies a request, Traefik logs show only the final 302 redirect. The internal subrequest to OAuth2-Proxy and its response are not logged by default, making it very hard to diagnose why auth is failing.

When to Use

  • Kubernetes clusters with multiple web services (dashboards, APIs, admin panels) that all need the same authentication gate
  • Projects using Traefik as the ingress controller where you want to avoid adding auth logic to each individual service
  • Environments where you need a centralized identity provider (SSO) with user management, realm isolation, and OIDC compliance

When NOT to Use

  • Single-service deployments: If you only have one service, embedding auth directly (e.g., Passport.js, Spring Security) is simpler than deploying Keycloak + OAuth2-Proxy as separate services.
  • API-only backends without browser clients: ForwardAuth relies on browser cookie sessions. For pure API authentication (mobile apps, service-to-service), use JWT validation middleware directly instead.
  • Environments without Traefik: ForwardAuth is a Traefik-specific middleware. If you use Nginx or another ingress controller, look at auth_request (Nginx) or equivalent mechanisms instead.
  • Lightweight projects where Keycloak is overkill: Keycloak is a full-featured IAM server with significant resource requirements. For simple username/password auth, consider lighter alternatives like Authelia or Authentik.

Let’s break this down piece by piece, starting with an analogy that makes the whole architecture click.

Table of Contents

  1. The Big Picture: A Building Analogy
  2. What is Traefik?
  3. What is Keycloak?
  4. The Problem: No Security
  5. What is ForwardAuth?
  6. Who is OAuth2-Proxy?
  7. The Complete Login Flow
  8. Complete Architecture Diagram
  9. Glossary

The Big Picture: A Building Analogy

Imagine your application (Crucio) is a fancy building with different rooms:

RoomWhat’s Inside
Grafana roomMonitoring dashboards
API roomWhere apps talk to the backend
Web roomThe main lobby/website
Keycloak roomThe membership office

Right now, anyone can walk into any room. We want to add security so only members can enter certain rooms.

What is Traefik?

The Simple Answer

Traefik is a doorman/bouncer that stands at the entrance of your building.

THE INTERNET (Everyone outside)
        │
        ▼
┌─────────────────────────────┐
│                             │
│    🚪 TRAEFIK (Doorman)     │
│                             │
│  "Where do you want to go?" │
│                             │
└──────────────┬──────────────┘
               │
    ┌──────────┼──────────┐
    │          │          │
    ▼          ▼          ▼
┌───────┐ ┌───────┐ ┌──────────┐
│Grafana│ │  API  │ │   Web    │
│ Room  │ │ Room  │ │  Lobby   │
└───────┘ └───────┘ └──────────┘

What Traefik Does

JobWhat It Means
Routing“You want /grafana? Go to the Grafana room!”
Security“I’ll add security features to protect you”
Load Balancing“Room is full? Let me send you to another one”

In Project Crucio

When someone visits https://crucio.brandonwie.dev/grafana, Traefik:

  1. Receives the request
  2. Looks at the URL path (/grafana)
  3. Says “Ah, you want Grafana!” and sends you there

Technical Details

  • Type: Ingress Controller (Kubernetes component that handles incoming traffic)
  • Location in Project: infra/k3s/system/traefik/
  • Key Files:
    • ingressroute-*.yaml - Define which URLs go to which services
    • middleware-*.yaml - Add features like rate limiting, security headers

What is Keycloak?

The Simple Answer

Keycloak is a membership office that issues ID cards and checks if they’re valid.

┌─────────────────────────────────────────────┐
│                                             │
│    🏢 KEYCLOAK (Membership Office)          │
│                                             │
│    "I keep track of all members"            │
│    "I give out membership cards"            │
│    "I verify if cards are real"             │
│                                             │
│    📋 Member Database:                      │
│    - testuser (password: testpassword)      │
│    - admin (password: crucio_admin_dev)     │
│                                             │
└─────────────────────────────────────────────┘

What Keycloak Does

JobWhat It Means
Stores UsersHas a database of usernames and passwords
Issues TokensWhen you log in, it gives you a “membership card” (JWT token)
Verifies TokensOther services can ask “Is this card real?”

In Project Crucio

  • URL: https://crucio.brandonwie.dev/auth/
  • Location in Project: infra/k3s/security/keycloak/
  • Status: Deployed and running, ready to issue membership cards

Key Concepts

TermMeaning
RealmA tenant/workspace in Keycloak (we use “crucio” realm)
ClientAn application that uses Keycloak (e.g., crucio-web, crucio-api)
OIDCOpenID Connect - the protocol for authentication

The Problem: No Security

Current Situation (INSECURE):

User → "I want to see Grafana"
         │
         ▼
    ┌──────────┐
    │ Traefik  │
    │ Doorman  │
    └────┬─────┘
         │
         │  "Sure, come right in!"
         │  (No questions asked)
         │
         ▼
    ┌──────────┐
    │ Grafana  │  ← Anyone can see your dashboards!
    └──────────┘

The problem: Traefik is a lazy doorman. It doesn’t check if you’re a member.

What is ForwardAuth?

The Simple Answer

ForwardAuth is teaching the doorman to check membership cards.

Instead of letting everyone in, Traefik will now:

  1. Stop you at the door
  2. Ask “Do you have a valid membership card?”
  3. If no → Send you to the membership office to get one
  4. If yes → Let you in

The New Flow (SECURE)

User → "I want to see Grafana"
         │
         ▼
    ┌──────────────────────────────────────────┐
    │  Traefik Doorman                          │
    │                                          │
    │  "Wait! Let me check your membership"    │
    │                                          │
    │  [Whispers to OAuth2-Proxy]              │
    │  "Hey, is this person a member?"         │
    └─────────────────────────┬────────────────┘
                              │
              ┌───────────────┴───────────────┐
              │                               │
              ▼                               ▼
    ┌──────────────────┐           ┌──────────────────┐
    │  "YES, they're   │           │  "NO, never seen │
    │   a member!"     │           │   them before"   │
    └────────┬─────────┘           └────────┬─────────┘
             │                              │
             ▼                              ▼
    ┌──────────────────┐           ┌──────────────────┐
    │  "Welcome to     │           │  "Go to the      │
    │   Grafana!"      │           │   membership     │
    │                  │           │   office first!" │
    │   🎉 Access!     │           │                  │
    └──────────────────┘           │  → Keycloak      │
                                   │  → Login Page    │
                                   │  → Get card      │
                                   │  → Come back     │
                                   └──────────────────┘

Technical Definition

ForwardAuth is a Traefik middleware that:

  1. Intercepts incoming requests
  2. Makes an internal “subrequest” to an authentication service
  3. If auth service returns 200 OK → Allow the request through
  4. If auth service returns 401/302 → Redirect to login

Who is OAuth2-Proxy?

Why Do We Need It?

Traefik is a doorman, not a security expert. It can ask “is this person a member?” but it doesn’t know how to verify membership cards.

OAuth2-Proxy is the security guard that:

  1. Knows how to read membership cards (JWT tokens)
  2. Knows how to talk to Keycloak
  3. Handles the whole “go get a card, come back with it” dance
┌─────────────────────────────────────────────────────────────────────┐
│                                                                     │
│  Traefik (Doorman)          OAuth2-Proxy           Keycloak        │
│      👔                     (Security Guard)       (Membership     │
│                                   🔐                 Office)        │
│                                                        🏢           │
│                                                                     │
│  "Is this person            "Let me check...        "Yes, that's   │
│   a member?"      ───────►   I'll ask Keycloak"  ───► testuser!"   │
│                                                                     │
│                             "Keycloak says yes!"                    │
│  "OK, let them in" ◄───────                                        │
│                                                                     │
└─────────────────────────────────────────────────────────────────────┘

Technical Details

  • Image: quay.io/oauth2-proxy/oauth2-proxy:v7.x
  • Port: 4180 (internal only)
  • Protocol: Implements OAuth2/OIDC flows
  • Session Storage: Secure HTTP-only cookies

Now that we understand each component’s role, let’s trace through a complete login flow to see how they work together in practice.

The Complete Login Flow

Step-by-Step: First Visit to /grafana

Step 1: You Visit Grafana

You: "I want to see https://crucio.brandonwie.dev/grafana"

Step 2: Traefik Checks ForwardAuth

Traefik: "Hold on! Let me check with the security guard."

Traefik → OAuth2-Proxy: "Is this person allowed in?"
OAuth2-Proxy: "I don't see a membership card cookie. Denied!"

OAuth2-Proxy → Traefik: "Send them to Keycloak to log in"

Step 4: Redirect to Login Page

Traefik → You: "You need to log in first!"

Browser redirects to: https://crucio.brandonwie.dev/auth/realms/crucio/login

Step 5: You Log In at Keycloak

┌─────────────────────────────────────┐
│         KEYCLOAK LOGIN              │
│                                     │
│   Username: [testuser          ]    │
│   Password: [••••••••••       ]    │
│                                     │
│          [ LOG IN ]                 │
└─────────────────────────────────────┘

Step 6: Keycloak Issues a Code

Keycloak: "Password correct! Here's a temporary code."

Keycloak → Browser: "Go to https://crucio.brandonwie.dev/oauth2/callback?code=ABC123"

Step 7: OAuth2-Proxy Exchanges Code for Token

Browser arrives at: /oauth2/callback?code=ABC123

OAuth2-Proxy → Keycloak: "Here's code ABC123, give me a real token"

Keycloak → OAuth2-Proxy: "Here's a JWT token proving testuser is logged in"

OAuth2-Proxy: "I'll save this in a cookie on the user's browser"

Step 8: You’re Redirected Back to Grafana

OAuth2-Proxy → Browser: "Here's a cookie. Now go back to /grafana"

Browser: *Has cookie now* → Goes to /grafana

Step 9: This Time, You Get In

Traefik: "Let me check with security guard again"

Traefik → OAuth2-Proxy: "Is this person allowed?"

OAuth2-Proxy: "Yes! They have a valid cookie!" ✅

Traefik → You: "Welcome to Grafana! 🎉"

Sequence Diagram

┌──────┐     ┌─────────┐     ┌──────────────┐     ┌──────────┐     ┌─────────┐
│ User │     │ Traefik │     │ OAuth2-Proxy │     │ Keycloak │     │ Grafana │
└──┬───┘     └────┬────┘     └──────┬───────┘     └────┬─────┘     └────┬────┘
   │              │                 │                  │                │
   │ GET /grafana │                 │                  │                │
   │─────────────>│                 │                  │                │
   │              │                 │                  │                │
   │              │ Check auth      │                  │                │
   │              │────────────────>│                  │                │
   │              │                 │                  │                │
   │              │ 302 (no cookie) │                  │                │
   │              │<────────────────│                  │                │
   │              │                 │                  │                │
   │ 302 Redirect to /auth/login    │                  │                │
   │<─────────────│                 │                  │                │
   │              │                 │                  │                │
   │ GET /auth/realms/crucio/login  │                  │                │
   │───────────────────────────────────────────────────>│                │
   │              │                 │                  │                │
   │ Login Page   │                 │                  │                │
   │<───────────────────────────────────────────────────│                │
   │              │                 │                  │                │
   │ POST (username/password)       │                  │                │
   │───────────────────────────────────────────────────>│                │
   │              │                 │                  │                │
   │ 302 to /oauth2/callback?code=ABC                  │                │
   │<───────────────────────────────────────────────────│                │
   │              │                 │                  │                │
   │ GET /oauth2/callback?code=ABC  │                  │                │
   │─────────────────────────────────>│                │                │
   │              │                 │                  │                │
   │              │                 │ Exchange code    │                │
   │              │                 │─────────────────>│                │
   │              │                 │                  │                │
   │              │                 │ JWT Token        │                │
   │              │                 │<─────────────────│                │
   │              │                 │                  │                │
   │ 302 to /grafana + Set-Cookie   │                  │                │
   │<─────────────────────────────────│                │                │
   │              │                 │                  │                │
   │ GET /grafana (with cookie)     │                  │                │
   │─────────────>│                 │                  │                │
   │              │                 │                  │                │
   │              │ Check auth      │                  │                │
   │              │────────────────>│                  │                │
   │              │                 │                  │                │
   │              │ 200 OK ✓        │                  │                │
   │              │<────────────────│                  │                │
   │              │                 │                  │                │
   │              │ Forward to Grafana                 │                │
   │              │────────────────────────────────────────────────────>│
   │              │                 │                  │                │
   │ Grafana Dashboard              │                  │                │
   │<───────────────────────────────────────────────────────────────────│
   │              │                 │                  │                │

Complete Architecture Diagram

                    THE INTERNET
                         │
                         ▼
    ┌────────────────────────────────────────────────────────┐
    │              CLOUDFLARE (Security Wall)                │
    │         DDoS protection, SSL/TLS encryption            │
    └────────────────────────────────────────────────────────┘
                         │
                         ▼
    ┌────────────────────────────────────────────────────────┐
    │                                                        │
    │              🚪 TRAEFIK (Doorman)                       │
    │                                                        │
    │   "Every request comes through me"                     │
    │   "I check ForwardAuth before letting anyone in"       │
    │                                                        │
    └───────────────┬─────────────────────────────┬──────────┘
                    │                             │
                    │ Protected Routes            │ Unprotected
                    │ (/grafana, /admin)          │ (/auth, /api)
                    ▼                             │
    ┌────────────────────────────────────┐        │
    │                                    │        │
    │  🔐 OAUTH2-PROXY (Security Guard)  │        │
    │                                    │        │
    │  "Is this cookie valid?"           │        │
    │  "Let me verify with Keycloak"     │        │
    │                                    │        │
    └─────────────┬──────────────────────┘        │
                  │                               │
                  │ Validates with                │
                  ▼                               │
    ┌────────────────────────────────────┐        │
    │                                    │        │
    │  🏢 KEYCLOAK (Membership Office)   │◄───────┘
    │                                    │   (Users log in here)
    │  - User database                   │
    │  - Token issuing                   │
    │  - Token verification              │
    │                                    │
    └────────────────────────────────────┘
                  │
                  │ If verified ✅
                  ▼
    ┌────────────────────────────────────┐
    │                                    │
    │  📊 GRAFANA (Protected Service)    │
    │                                    │
    │  Only authenticated users see this │
    │                                    │
    └────────────────────────────────────┘

Glossary

TermPlain EnglishTechnical Definition
TraefikDoorman that routes you to the right roomKubernetes Ingress Controller
KeycloakMembership office that knows all membersIdentity and Access Management (IAM) server
OAuth2-ProxySecurity guard that checks your cardAuthentication proxy that handles OAuth2/OIDC flows
ForwardAuthThe rule that says “check cards before entering”Traefik middleware that delegates auth to external service
JWT TokenYour digital membership cardJSON Web Token - signed data proving identity
CookieWhere your browser stores your cardBrowser storage for session data
OIDCThe language the membership office speaksOpenID Connect - authentication protocol built on OAuth2
RealmA separate membership databaseKeycloak tenant/workspace
ClientAn app registered with the membership officeOAuth2 client application
MiddlewareExtra checks the doorman performsTraefik plugin that processes requests
IngressThe building’s front doorKubernetes resource for external access
SubrequestDoorman’s whisper to security guardInternal HTTP request for auth check

Project Crucio Files Reference

ComponentLocationPurpose
Traefik Routesinfra/k3s/system/traefik/ingressroute-*.yamlDefine URL routing
Traefik Middlewaresinfra/k3s/system/traefik/middleware-*.yamlSecurity headers, rate limiting
Keycloakinfra/k3s/security/keycloak/Identity provider deployment
OAuth2-Proxyinfra/k3s/security/oauth2-proxy/ForwardAuth handler
ForwardAuth Middlewareinfra/k3s/system/traefik/middleware-forwardauth.yamlTraefik ForwardAuth config

With the architecture understood, here’s the step-by-step deployment guide for setting up this stack in your own Kubernetes cluster.

Deployment Setup Guide

Prerequisites

Before deploying OAuth2-Proxy, ensure:

  1. Keycloak is running: kubectl get pods -n crucio-security -l app.kubernetes.io/name=keycloak
  2. ‘crucio’ realm exists: Created in T3.1.2
  3. Test user exists: Created in T3.1.3

Step 1: Create OAuth2-Proxy Client in Keycloak

This is a MANUAL STEP that must be done before deploying OAuth2-Proxy.

  1. Access Keycloak Admin Console:

    kubectl port-forward svc/keycloak -n crucio-security 8080:8080

    Then open: http://localhost:8080/auth/admin/

  2. Login as admin:

    • Username: admin
    • Password: crucio_admin_dev

  3. Select ‘crucio’ realm (dropdown in top-left)

  4. Create new client:

    • Navigate: Clients → Create client
    • Client ID: oauth2-proxy
    • Client Protocol: openid-connect
    • Click: Next

  5. Configure client settings:

    • Client Authentication: ON (Confidential client)
    • Authorization: OFF
    • Standard flow: ON
    • Direct access grants: OFF
    • Click: Next

  6. Set redirect URIs:

    • Valid Redirect URIs: https://crucio.brandonwie.dev/oauth2/callback
    • Add additional URIs as needed:
      • https://grafana.brandonwie.dev/oauth2/callback
      • https://api.brandonwie.dev/oauth2/callback
    • (For local dev, add: http://localhost/oauth2/callback)
    • Click: Save

  7. Copy client secret:

    • Go to: Credentials tab
    • Copy the “Client Secret” value
    • You’ll need this for the secret.yaml

OAuth2-Proxy needs a secret key to encrypt session cookies.

# Generate 32-byte base64url-encoded secret
python3 -c 'import os,base64; print(base64.urlsafe_b64encode(os.urandom(32)).decode())'

Save the output - you’ll need it for secret.yaml.

Step 3: Update Secret Values

Edit infra/k3s/security/oauth2-proxy/secret.yaml:

  1. Replace client secret:

    # Take the secret from Keycloak step 7
echo -n 'your-keycloak-client-secret-here' | base64
# Paste result into OAUTH2_PROXY_CLIENT_SECRET

  2. Replace cookie secret:

    # Take the output from step 2
echo -n 'your-generated-cookie-secret' | base64
# Paste result into OAUTH2_PROXY_COOKIE_SECRET

Step 4: Deploy OAuth2-Proxy

# Deploy OAuth2-Proxy
kubectl apply -k infra/k3s/security/oauth2-proxy/

# Verify deployment
kubectl get pods -n crucio-security -l app.kubernetes.io/name=oauth2-proxy

# Check logs for any errors
kubectl logs -n crucio-security -l app.kubernetes.io/name=oauth2-proxy

Step 5: Deploy ForwardAuth Middleware

# Deploy ForwardAuth middleware
kubectl apply -f infra/k3s/system/traefik/middleware-forwardauth.yaml

# Verify middleware created
kubectl get middleware -n crucio-system forwardauth-oauth2

Step 6: Update Grafana Route

# Apply updated Grafana IngressRoute (now includes ForwardAuth)
kubectl apply -f infra/k3s/system/traefik/ingressroute-grafana.yaml

Verification

  1. Test OAuth2-Proxy health:

    kubectl port-forward svc/oauth2-proxy -n crucio-security 4180:4180
curl http://localhost:4180/ping
# Should return: OK

  2. Test Grafana with auth:

  3. Test logout:

Troubleshooting

ProblemCauseSolution
502 Bad GatewayOAuth2-Proxy not runningCheck pods: kubectl get pods -n crucio-security
Redirect loopInvalid redirect URIVerify Keycloak client’s Valid Redirect URIs
“Invalid issuer”Wrong OIDC URLCheck OAUTH2_PROXY_OIDC_ISSUER_URL in configmap
Cookie not setWrong domainCheck OAUTH2_PROXY_COOKIE_DOMAINS matches your domain
“Invalid client secret”Secret mismatchRe-copy secret from Keycloak

Debug Commands

# Check OAuth2-Proxy logs
kubectl logs -n crucio-security -l app.kubernetes.io/name=oauth2-proxy -f

# Check Traefik logs for routing issues
kubectl logs -n kube-system -l app.kubernetes.io/name=traefik -f

# Test OIDC discovery endpoint
kubectl exec -n crucio-security deploy/oauth2-proxy --
  wget -qO- http://keycloak.crucio-security:8080/auth/realms/crucio/.well-known/openid-configuration

Next Steps

After completing T3.1.4:

  1. T3.1.5: Update API to validate Keycloak tokens (replace local JWT)
  2. T3.2.1: Create guardrails service (PII masking + injection detection)
  3. Enable Grafana Auth Proxy: Configure Grafana to use X-Auth-Request-User header

Optional: Enable Grafana Auth Proxy Mode

To enable automatic login in Grafana based on ForwardAuth headers, update grafana.ini:

[auth.proxy]
enabled = true
header_name = X-Auth-Request-User
header_property = username
auto_sign_up = true

This allows Grafana to automatically create and login users based on the X-Auth-Request-User header set by OAuth2-Proxy.

Practical Takeaways

The Traefik + Keycloak + OAuth2-Proxy stack gives you centralized authentication for any number of Kubernetes services — without touching a single line of application code. Here’s what to keep in mind:

  1. ForwardAuth is the key concept. It turns Traefik from a simple reverse proxy into an authentication gateway. Every request gets checked against OAuth2-Proxy before reaching the target service. The services themselves remain auth-agnostic.

  2. Cookie domain mismatches cause silent redirect loops. If OAuth2-Proxy sets a cookie on example.com but the service runs on app.example.com, the browser never sends the cookie back. You get an infinite redirect loop with no useful error message. Double-check OAUTH2_PROXY_COOKIE_DOMAINS before anything else.

  3. Cross-namespace middleware references fail silently. If your ForwardAuth middleware is in a different Kubernetes namespace than the IngressRoute, Traefik won’t error — it just bypasses auth entirely. Use the middleware@namespace syntax or keep middleware and routes in the same namespace.

  4. Keycloak is powerful but heavy. If you only need simple username/password auth for a few services, consider lighter alternatives like Authelia or Authentik. Keycloak shines when you need SSO across many services, realm isolation, or enterprise OIDC compliance.

The building analogy in this post maps directly to the architecture: Traefik is the doorman (routing), OAuth2-Proxy is the security guard (auth verification), and Keycloak is the membership office (identity management). Each has a clear, single responsibility.

Comments

enko
