AWS VPC Networking Fundamentals

I spent my first week on AWS wondering why my EC2 instance in a “private subnet” was reachable from the internet, and why the NAT Gateway I placed next to my application wasn’t doing anything — except costing me $32/month. VPC networking is one of those topics where a small misunderstanding cascades into hours of debugging and unexpected bills.

This post is the guide I wish I’d had: a ground-up walkthrough of AWS VPC networking, from CIDR math to NAT Gateway placement to Terraform configuration. If you’ve ever stared at a route table wondering why your traffic isn’t flowing, this is for you.

The Problem

AWS resources need an isolated network to communicate securely. Without understanding VPC fundamentals — CIDR notation, subnet design, route tables, and gateway placement — you end up with resources that cannot reach the internet, private subnets that are accidentally public, NAT Gateways in the wrong subnet burning money without working, or address spaces too small to accommodate growth. VPC is the foundation that every other AWS service builds on, and mistakes here cascade into every layer above.

Difficulties Encountered

CIDR math is not intuitive — calculating available IPs from a prefix length requires understanding binary math (2^(32-prefix)), and forgetting that AWS reserves 5 IPs per subnet means a /28 only gives you 11 usable addresses, not 16
NAT Gateway placement is counterintuitive — the NAT Gateway must live in a public subnet to give private subnet resources internet access; placing it in the private subnet (where the resources that need it are) seems logical but breaks routing entirely
Subnet IP count vs connection capacity confusion — a /24 subnet with 251 usable IPs does not mean 251 maximum connections; each EC2 instance uses one IP but can handle thousands of connections, so subnet sizing is about resource count, not traffic capacity
Route table association is implicit — subnets not explicitly associated with a route table use the VPC’s main route table, which can accidentally make a “private” subnet public if the main route table has an IGW route
NAT Gateway costs are surprisingly high — at ~$32/month plus data processing fees, a NAT Gateway for a dev environment is an expensive oversight; this is easy to miss because Terraform creates it without cost warnings

When to Use

Any AWS deployment that needs network isolation (which is nearly all of them)
Multi-tier architectures with public-facing and internal-only resources
Production environments requiring private subnets for databases and application servers
Environments needing controlled internet access from private resources (via NAT Gateway)

When NOT to Use

Serverless-only architectures with no VPC resources — Lambda functions that only call external APIs and DynamoDB do not need a VPC; adding one increases cold start latency and requires NAT Gateway for internet access
Simple S3 + CloudFront static sites — no compute resources means no VPC needed; adding one adds cost and complexity with zero benefit
Quick prototyping with default VPC — AWS provides a default VPC in every region with public subnets pre-configured; for throwaway experiments, use it instead of building custom VPC infrastructure
Single-AZ development environments — a full multi-AZ VPC with NAT Gateways per AZ is production architecture; dev environments can use a single AZ with a simpler setup to save ~$64/month on redundant NAT Gateways
Cross-region networking at scale — a single VPC cannot span regions; for multi-region architectures, you need VPC Peering or Transit Gateway, which are separate concepts with their own design patterns

With those constraints in mind, let’s start with the foundation of VPC design: IP addressing.

IP Addressing and CIDR

CIDR Notation Basics

IP addresses (IPv4) are 32-bit numbers, typically written as 4 octets separated by dots (e.g., 10.0.1.5). Each octet ranges from 0-255.

CIDR (Classless Inter-Domain Routing) notation: base_address/prefix_length

Example: 10.0.0.0/24
- 10.0.0.0 = base address
- /24 = first 24 bits are network portion (fixed)
- Remaining 8 bits = host portion (variable)

Prefix Length to IP Address Count

Prefix	Host Bits	Total IPs	AWS Usable
/32	0	1	Single IP
/28	4	16	11
/27	5	32	27
/26	6	64	59
/25	7	128	123
/24	8	256	251
/23	9	512	507
/22	10	1,024	1,019
/16	16	65,536	Common VPC size

Formula: 2^(32-prefix_length) = total IPs

AWS Reserved IPs

In each subnet, AWS reserves 5 IP addresses:

10.0.1.0/24 subnet:
10.0.1.0   - Network address (reserved)
10.0.1.1   - AWS gateway (reserved)
10.0.1.2   - AWS DNS (reserved)
10.0.1.3   - AWS future use (reserved)
10.0.1.255 - Broadcast address (reserved)

Usable: 10.0.1.4 to 10.0.1.254 (251 addresses)

One common misconception about these numbers deserves its own section.

Subnet IP vs Connection Capacity

Important clarification: Subnet IP count ≠ connection capacity.

IP addresses limit resources you can deploy (EC2, RDS, etc.)
Each EC2 instance can handle thousands of concurrent connections
Connection capacity depends on instance type and application design

Example architecture:

/24 subnet (251 usable IPs):
- 5 EC2 instances (5 IPs)
- 1 RDS instance (1 IP)
- 1 ElastiCache (1 IP)
- Each EC2 handles 2,000 connections
- Total capacity: ~10,000 concurrent connections

Now that we understand IP addressing and subnet sizing, let’s put it together into a VPC architecture.

VPC Architecture

Standard VPC Design

A VPC is your isolated network within AWS. The CIDR block you choose determines the total address space available for all subnets within it.

resource "aws_vpc" "main" {
  cidr_block           = "10.0.0.0/16"  # 65,536 IPs
  enable_dns_hostnames = true
  tags = { Name = "production-vpc" }
}

Subnet Layout Convention

VPC: 10.0.0.0/16

Public Subnets (internet-facing):
├── 10.0.1.0/24  - AZ-a public
├── 10.0.2.0/24  - AZ-b public
├── 10.0.3.0/24  - AZ-c public
└── 10.0.4.0/24  - AZ-d public

Private Subnets (internal):
├── 10.0.11.0/24 - AZ-a private
├── 10.0.12.0/24 - AZ-b private
├── 10.0.13.0/24 - AZ-c private
└── 10.0.14.0/24 - AZ-d private

Convention benefits:

Predictable IP patterns
Easy to identify subnet purpose from IP
Room for expansion
Clear security boundaries

With subnets defined, we need components that control how traffic flows in and out of the VPC.

Network Components

Internet Gateway (IGW)

The Internet Gateway is the VPC’s connection point to the public internet. Think of it as the building’s front door — without it, nothing inside the VPC can reach the outside world.

Connects VPC to the internet
One IGW per VPC (hard limit)
No IP address consumption
Enables public subnet internet access

resource "aws_internet_gateway" "main" {
  vpc_id = aws_vpc.main.id
}

NAT Gateway

NAT Gateway enables private subnet resources to access the internet (outbound only).

Critical placement rule: NAT Gateway must be in a public subnet.

B[Process] --> C[Output] `} /> ``` NOTE: Curly braces in mermaid code will be interpreted as Svelte expressions. Either escape them or avoid using braces in labels. REFERENCES: - MDsveX + Mermaid issue: https://github.com/pngwn/MDsveX/issues/737 - MDsveX plugin discussion: https://github.com/pngwn/MDsveX/discussions/354 - Svelte Mermaid approach: https://jamesjoy.site/posts/2023-06-26-svelte-mermaidjs -->

Loading diagram...

# EIP for NAT Gateway
resource "aws_eip" "nat" {
  domain     = "vpc"
  depends_on = [aws_internet_gateway.main]
}

# NAT Gateway in PUBLIC subnet
resource "aws_nat_gateway" "main" {
  subnet_id     = aws_subnet.public_a.id  # Must be public!
  allocation_id = aws_eip.nat.id
  depends_on    = [aws_internet_gateway.main]
}

Cost consideration: NAT Gateway costs ~$32/month + data processing fees. Only create if private subnets need internet access.

IGW-to-EIP Dependency Ordering

The depends_on on the EIP and NAT Gateway resources is not about IP assignment — it is about creation ordering. The Internet Gateway must exist and be attached to the VPC before the EIP and NAT Gateway are created, because the NAT Gateway needs a functioning internet path to operate.

Key facts about IGW and EIP:

IGW does not consume or assign IP addresses — it is a logical connection point between VPC and internet
One VPC can have at most one IGW (AWS hard limit)
EIP is not attached to the IGW — it is attached to the NAT Gateway (or an EC2 instance)
depends_on takes a list (array syntax) even for a single dependency

resource "aws_eip" "nat" {
  domain     = "vpc"
  # Ordering: IGW must exist before EIP is created
  depends_on = [aws_internet_gateway.main]
}

resource "aws_nat_gateway" "main" {
  subnet_id     = aws_subnet.public_a.id
  allocation_id = aws_eip.nat.id
  # Same ordering: IGW must exist before NAT GW is created
  depends_on = [aws_internet_gateway.main]
}

Without depends_on, Terraform may create the EIP and NAT Gateway in parallel with the IGW. This can cause intermittent failures because AWS APIs are asynchronous — the NAT Gateway creation may succeed but the gateway cannot route traffic until the IGW is fully attached.

Elastic IP (EIP)

Static public IP address
Persists across instance stop/start
Free when attached to running instance
Charged when unattached (~$3.6/month)

IP Setup Options Comparison

Five approaches exist for assigning public-facing IPs to AWS resources, each with different cost and flexibility trade-offs:

Option	Cost	Fixed IP	Survives Stop/Start	Best For
Default Public IP	Free (included with EC2)	No	No	Dev/test, behind LB
Load Balancer + Public IP	LB cost only (~$16/month)	DNS name	N/A	Production HA clusters
Route 53 + Default Public IP	~$0.50/month + query fees	DNS name	Short TTL needed	Budget-friendly domain routing
Private IP + NAT Gateway	NAT GW shared (~$32/month + data)	No	N/A	Backend services, no direct access
Elastic IP (attached)	Free when attached to running EC2	Yes	Yes	Fixed IP requirement (NAT GW, EC2)

Cost-driven decision guide:

No fixed IP needed — Use default public IP (free)
Multiple servers, single endpoint — Load Balancer + default public IP
Fixed name needed, IP does not matter — Route 53 + default public IP
Fixed IP required — Elastic IP (free when properly attached)
No public exposure — Private subnet + shared NAT Gateway

Note on NAT Gateway EIP: The Terraform code uses an EIP for the NAT Gateway. This is required because the NAT Gateway needs a stable public IP for outbound traffic from private subnets. This EIP is free as long as it remains attached to the NAT Gateway.

Gateways and EIPs provide the ability to reach the internet, but route tables determine which subnets actually use them.

Route Tables

Public Route Table

The public route table sends all non-local traffic (0.0.0.0/0) through the Internet Gateway, making any associated subnet “public”:

resource "aws_route_table" "public" {
  vpc_id = aws_vpc.main.id

  route {
    cidr_block = "0.0.0.0/0"
    gateway_id = aws_internet_gateway.main.id
  }
}

resource "aws_route_table_association" "public_a" {
  subnet_id      = aws_subnet.public_a.id
  route_table_id = aws_route_table.public.id
}

Private Route Table

The private route table sends outbound traffic through the NAT Gateway instead, keeping resources hidden from direct internet access while still allowing them to reach external services:

resource "aws_route_table" "private" {
  vpc_id = aws_vpc.main.id

  route {
    cidr_block     = "0.0.0.0/0"
    nat_gateway_id = aws_nat_gateway.main.id  # Note: nat_gateway_id, not gateway_id
  }
}

resource "aws_route_table_association" "private_a" {
  subnet_id      = aws_subnet.private_a.id
  route_table_id = aws_route_table.private.id
}

With route tables configured, here’s how traffic actually flows through the VPC for different scenarios.

Traffic Flow

Public Subnet Traffic

Internet → IGW → Public Route Table → Public Subnet → EC2

Private Subnet Outbound

EC2 (private) → Private Route Table → NAT Gateway → IGW → Internet

Private Subnet Inbound (via ALB)

Internet → IGW → ALB (public) → EC2 (private)

AWS Billing for VPC

Free resources:

VPC itself
Subnets
Route tables
Security groups
Network ACLs
Private IP addresses

Charged resources:

NAT Gateway (~$0.045/hour + data)
Elastic IP (when unattached)
Data transfer (cross-AZ, internet egress)
VPN connections
Transit Gateway

Understanding the cost model helps you make informed decisions about which components to include — especially for non-production environments where a NAT Gateway might not be worth the $32/month.

Now let’s put everything together into a complete, production-ready Terraform configuration.

Complete VPC Example

The following Terraform code creates a VPC with one public subnet, one private subnet, an Internet Gateway, and a NAT Gateway — the minimal production setup for a single availability zone:

# VPC
resource "aws_vpc" "main" {
  cidr_block           = "10.0.0.0/16"
  enable_dns_hostnames = true
  tags = { Name = "production-vpc" }
}

# Public subnet
resource "aws_subnet" "public_a" {
  vpc_id                  = aws_vpc.main.id
  cidr_block              = "10.0.1.0/24"
  availability_zone       = "ap-northeast-2a"
  map_public_ip_on_launch = true
  tags = { Name = "public-subnet-a" }
}

# Private subnet
resource "aws_subnet" "private_a" {
  vpc_id            = aws_vpc.main.id
  cidr_block        = "10.0.11.0/24"
  availability_zone = "ap-northeast-2a"
  tags = { Name = "private-subnet-a" }
}

# Internet Gateway
resource "aws_internet_gateway" "main" {
  vpc_id = aws_vpc.main.id
  tags = { Name = "main-igw" }
}

# NAT Gateway (in public subnet)
resource "aws_eip" "nat" {
  domain     = "vpc"
  depends_on = [aws_internet_gateway.main]
}

resource "aws_nat_gateway" "main" {
  subnet_id     = aws_subnet.public_a.id
  allocation_id = aws_eip.nat.id
  depends_on    = [aws_internet_gateway.main]
  tags = { Name = "main-nat" }
}

# Public route table
resource "aws_route_table" "public" {
  vpc_id = aws_vpc.main.id
  route {
    cidr_block = "0.0.0.0/0"
    gateway_id = aws_internet_gateway.main.id
  }
  tags = { Name = "public-rt" }
}

# Private route table
resource "aws_route_table" "private" {
  vpc_id = aws_vpc.main.id
  route {
    cidr_block     = "0.0.0.0/0"
    nat_gateway_id = aws_nat_gateway.main.id
  }
  tags = { Name = "private-rt" }
}

# Associations
resource "aws_route_table_association" "public_a" {
  subnet_id      = aws_subnet.public_a.id
  route_table_id = aws_route_table.public.id
}

resource "aws_route_table_association" "private_a" {
  subnet_id      = aws_subnet.private_a.id
  route_table_id = aws_route_table.private.id
}

Practical Takeaways

VPC networking is the invisible foundation of every AWS deployment. Get it right once, and every service you build on top inherits a secure, predictable network. Get it wrong, and you’ll spend hours debugging connectivity issues that could have been prevented by understanding three things:

CIDR math determines your growth ceiling. A /16 VPC gives you room for 65,536 addresses — start there unless you have a reason not to. Remember that AWS reserves 5 IPs per subnet, so a /28 only gives you 11 usable addresses.
NAT Gateway placement is counterintuitive by design. The NAT Gateway lives in the public subnet to give private subnet resources internet access. If you place it in the private subnet (where the resources are), routing breaks entirely. At ~$32/month, a NAT Gateway in a dev environment is an expensive mistake — skip it unless private subnets genuinely need outbound internet access.
Explicit route table associations prevent accidental exposure. Never rely on the default main route table. If someone adds an IGW route to it, every unassociated subnet becomes public. Always explicitly associate every subnet with its intended route table.

Start with the complete Terraform example above, adapt the CIDR ranges and AZs to your region, and build from there. For dev environments, a single-AZ setup without redundant NAT Gateways saves ~$64/month with no impact on development workflows.
