WebSocket Architecture in AWS ECS/ALB

Our users kept refreshing the page to check if their calendar sync was done. We needed the server to push a “sync complete” notification in real time — but our NestJS backend ran on multiple ECS containers behind an ALB. That raised a fundamental question: if a background job finishes on Container 2, how does User A (connected to Container 1) find out?

This post traces the full architecture of WebSocket connections in a containerized AWS environment: how ALB handles the HTTP upgrade, how Redis Pub/Sub bridges multiple containers, and what happens when connections inevitably drop.

The Problem

A NestJS backend running on AWS ECS needs to push real-time notifications to browser clients (e.g., “sync complete” after a background job finishes). HTTP polling wastes resources and adds latency. WebSockets solve this, but introducing them in a containerized, load-balanced environment raises questions: How does ALB handle the HTTP-to-WebSocket upgrade? How do multiple containers broadcast to clients connected to different instances? What happens when connections drop?

Difficulties Encountered

Misunderstanding ALB’s role — Initial assumption was that ALB actively manages WebSocket state; in reality ALB is just a TCP tunnel after the HTTP upgrade handshake. This confusion led to unnecessary ALB configuration attempts
Cross-container broadcasting — When User A connects to Container 1 but a sync job completes on Container 2, Container 2 cannot directly notify User A. Took time to understand that Redis Pub/Sub solves this via persistent TCP subscriptions, not HTTP callbacks
Connection lifecycle edge cases — Browser tab close sends a TCP FIN (not a WebSocket close frame), network drops send nothing (relies on ping/pong timeout), and ALB has its own idle timeout. Each scenario requires different handling, which was not obvious from Socket.io docs alone
Sticky sessions confusion — Thought sticky sessions were mandatory for Socket.io, but they are only needed for HTTP polling fallback. With WebSocket transport only, any container can handle the connection after the initial upgrade

Architecture Overview

B[Process] --> C[Output] `} /> ``` NOTE: Curly braces in mermaid code will be interpreted as Svelte expressions. Either escape them or avoid using braces in labels. REFERENCES: - MDsveX + Mermaid issue: https://github.com/pngwn/MDsveX/issues/737 - MDsveX plugin discussion: https://github.com/pngwn/MDsveX/discussions/354 - Svelte Mermaid approach: https://jamesjoy.site/posts/2023-06-26-svelte-mermaidjs -->

Loading diagram...

Connection Flow

Client sends HTTP request with Upgrade: websocket header
ALB receives request, routes to a container
Container accepts upgrade, establishes WebSocket
ALB keeps TCP tunnel open (passes through data)
Socket.io manages the connection from here

Let’s break down what each component in this architecture is actually responsible for.

Component Responsibilities

Component	Role
ALB	Routes initial HTTP upgrade, then passes through TCP (tunnel)
Socket.io Server	Manages WebSocket connection, tracks clients, handles heartbeats
NestJS Gateway	Application logic - auth, message handling, room management
Redis Adapter	Broadcasts messages across multiple containers

Key insight: ALB is just a tunnel - Socket.io manages the actual connection.

A natural question arises: if Socket.io manages the connection, why do we need an ALB at all? The answer is about network topology, not protocol handling.

Why We Need ALB

Initial Connection Routing

Without ALB:
  Client: "I want to connect to wss://api.example.com"
  Containers have private IPs:
  - 10.0.1.5:3000
  - 10.0.1.6:3000
  Client can't access private IPs directly!

With ALB:
  Client → api.example.com → ALB (public) → picks container → WebSocket established

ALB solves the “how do clients reach containers” problem. But there’s a second, subtler problem: how do containers talk to each other?

Redis for Multi-Container Broadcasting

The Problem

With multiple ECS containers, User A might connect to Container 1, but the sync job runs on Container 2.

Without Redis:
  User A ──────────────► Container 1 (User A's socket here)
  Sync Job ────────────► Container 2 (Sync completes here)
  Container 2 can't notify User A!

The Solution: Redis Pub/Sub

Loading diagram...

How Pub/Sub Actually Works

A common misconception is that Redis sends HTTP requests to your application when a message is published. In reality, it works the other way around — your app maintains persistent TCP connections to Redis, and Redis writes data to those already-open connections:

Step 1: STARTUP
  Container opens TCP connection to Redis (stays open!)
  → "SUBSCRIBE app:socket.io"

Step 2: PUBLISH
  Container 2 sends message to Redis
  → "PUBLISH app:socket.io {user:123, data:...}"

Step 3: PUSH
  Redis writes to the ALREADY OPEN TCP connection

Step 4: RECEIVE
  Node.js event loop picks up data from socket
  Socket.io adapter handles it → delivers to user's WebSocket

Code Reference

In the Socket.io Redis adapter setup, notice the two separate Redis clients — one for publishing messages, one for subscribing to receive them. The subscriber maintains a persistent TCP connection that Redis writes to whenever a message is published on the channel:

// pubClient: for PUBLISHING messages
// subClient: for SUBSCRIBING (maintains open TCP connection)
const pubClient = createClient({ url: redisUrl });
const subClient = pubClient.duplicate();

await Promise.all([pubClient.connect(), subClient.connect()]);

this.adapterConstructor = createAdapter(pubClient, subClient, {
  key: `${redisConfig.prefix}:socket.io`
});

With the broadcasting mechanism understood, the next important topic is what happens when connections end — either normally or unexpectedly.

Connection Lifecycle

Scenario A: Client Closes App/Tab (Normal)

Client closes browser
    ↓
Browser's TCP stack sends FIN packet (not Socket.io!)
    ↓
TCP FIN packet ──► ALB ──► Container
    ↓
Socket.io detects TCP connection closed
    ↓
handleDisconnect() called (auto room cleanup)

Why TCP FIN, not WebSocket message?

Browser is closing, no time for graceful WebSocket close
TCP FIN is faster and handled by OS, not JavaScript
Works even if JavaScript is frozen/crashed

Scenario B: Network Interruption

Network drops (no FIN packet)
    ↓
Socket.io ping/pong timeout (~25s)
    ↓
Server marks client as disconnected
    ↓
handleDisconnect() called

Scenario C: ALB Idle Timeout

No activity for 60 seconds (ALB default)
    ↓
ALB closes the TCP connection
    ↓
Both client and server detect disconnect

Note: This rarely happens because Socket.io sends heartbeat every 25s.

Summary Table

Initiator	Mechanism	Detection
Client (normal close)	TCP FIN	Immediate
Client (crash/network)	No FIN	Ping/pong timeout (~25s)
ALB	Idle timeout (60s)	TCP RST
Server	`client.disconnect()`	Immediate

ALB Idle Timeout (Why No Change Needed)

Setting	Default Value	What it does
ALB idle timeout	60 seconds	Closes connection if no data for 60s
Socket.io pingInterval	25 seconds	Sends ping every 25s
Socket.io pingTimeout	20 seconds	Waits 20s for pong response

Socket.io’s heartbeat keeps the connection alive:

Timeline:
0s   ─── Connection established
25s  ─── Socket.io sends PING → ALB resets idle timer
50s  ─── Socket.io sends PING → ALB resets idle timer
75s  ─── Socket.io sends PING → ALB resets idle timer
...

ALB idle timeout (60s) is NEVER reached because Socket.io
sends heartbeat every 25s. No config change needed!

Single Container Setup (Simplified)

For single-container deployments:

Component	Needed?	Why
ALB	Yes	Routes public traffic to private container
Redis Adapter	Yes	Future-proofs for multi-container
Sticky Sessions	No	Single container = all connections go same place
Multiple containers	No	Not needed until scale requires it

Multi-Container Considerations

When scaling to multiple containers:

Sticky Sessions

Ensures reconnections go to the same container:

Faster reconnection (previous state available)
Less Redis overhead
Required for Socket.io HTTP polling fallback

When to Use

Real-time notifications to browser clients — When the server needs to push updates (sync status, live collaboration, chat) without client polling
Containerized deployments behind a load balancer — When multiple ECS tasks or Kubernetes pods serve the same application and clients may connect to any instance
Background job completion alerts — When async workers finish tasks and users need immediate feedback without refreshing

When NOT to Use

Simple request-response APIs — If the client only needs data when it explicitly asks, REST or GraphQL is simpler and has no persistent connection overhead
Server-sent events (SSE) suffice — If communication is one-directional (server to client only), SSE is simpler than WebSocket and works through more proxies without special config
Low-frequency updates — If updates happen less than once per minute, long-polling or periodic fetch is cheaper than maintaining persistent WebSocket connections
Serverless / Lambda — WebSockets require persistent connections; Lambda functions are ephemeral. Use API Gateway WebSocket APIs instead of Socket.io in serverless environments

Options Considered

Option	Pros	Cons
Socket.io + Redis Adapter	Auto-reconnect, room management, fallback to polling, cross-container broadcast	Extra dependency (Redis); Socket.io adds protocol overhead
Raw WebSocket (ws library)	Minimal overhead; no abstraction layer	No auto-reconnect; manual room management; no cross-container broadcast without custom pub/sub
Server-Sent Events (SSE)	Simple; works through most proxies; no upgrade needed	Unidirectional (server to client only); no binary support
Long Polling	Works everywhere; no special infra	High latency; wastes server resources; complex client logic
AWS API Gateway WebSockets	Serverless; managed scaling	Vendor lock-in; different programming model; no Socket.io compatibility

Why This Approach

Chose Socket.io with Redis Adapter because the application needs bidirectional communication (client sends actions, server pushes notifications), automatic reconnection handling, and cross-container message broadcast. Raw WebSocket would require reimplementing all of Socket.io’s room management, heartbeat, and reconnection logic. SSE is unidirectional. The Redis Adapter was chosen over custom pub/sub because Socket.io’s adapter pattern handles serialization, namespaces, and room-scoped broadcasting out of the box.

Key Points

ALB is just a tunnel - Routes initial connection, then passes through TCP
Socket.io manages lifecycle - Ping/pong, timeouts, rooms, cleanup are automatic
Redis enables multi-container - Uses persistent TCP connections, not HTTP
Pub/Sub pattern - Subscribe once, receive messages as they’re published
Single container simplifies - No sticky sessions needed; Redis useful for future scaling

Practical Takeaways

WebSocket architecture in a containerized environment looks complex on paper, but the mental model is straightforward once you understand each component’s role:

ALB is just a tunnel. After the initial HTTP upgrade handshake, ALB does nothing but pass TCP bytes through. Socket.io manages the actual connection lifecycle — heartbeats, timeouts, rooms, cleanup. Don’t over-configure the ALB; the defaults work because Socket.io’s 25-second heartbeat keeps connections alive well within ALB’s 60-second idle timeout.
Redis Pub/Sub solves the multi-container broadcast problem. Each container maintains a persistent TCP connection to Redis. When Container 2 publishes a message, Redis writes it to Container 1’s already-open connection — no HTTP callbacks, no polling. The Socket.io Redis adapter handles serialization and room-scoped delivery out of the box.
Start with the Redis adapter even on a single container. It adds negligible overhead and means you can scale to multiple containers without changing your WebSocket code. Going from one container to three becomes a Terraform change, not an application architecture change.
Know the three disconnect scenarios. Normal tab close sends a TCP FIN (instant detection). Network drops send nothing (detected by ping/pong timeout in ~25 seconds). ALB idle timeout (60 seconds) rarely triggers thanks to heartbeats. Each scenario is handled automatically by Socket.io, but understanding them helps you debug connection issues in production.

If you’re adding real-time features to a containerized backend, the Socket.io + Redis Adapter + ALB combination is battle-tested and avoids reinventing the wheel of connection management, reconnection, and cross-container messaging.
